High Speed Automatic 4 Shaft Stretch Film Rewinder

PPD-4SH500

High speed automatic 4 shaft stretch film rewinder is our latest model for stretch film rewinding machine.
This model is rapidly change the shaft,4 shaft changing for non-stop production,it improves the production more than 50% than the market conventional model.

Features:
1. Four shaft cyclic winding, high work efficiency;
2. PLC + human-machine interface + frequency converter control system, easy to operate;
3. There will be an alarm if there is no paper tube in the paper tube hopper, and it will automatically stop if there is no paper tube in the chuck, which is very user-friendly.
4.High precision parts and clamping device, clamp accurately of the paper core, put the it to the rewinding station and pressure onto the rewinding roller to make the machine more automatically and user friendly.

Main Parameters:

Name:High Speed Automatic 4 Shaft Stretch Film Rewinder

Model:PPD-4SH500

Mother roll width:500mm

Mother roll outer diameter:max500mm

Mother roll inner diameter:3inch

Rewinding roll width:500mm

Rewinding roll inner diameter:1.5/2/3inch

Rewinding roll outer diameter: max150mm

Machine design speed:Max1200m/min

Total power:5.0kw

Voltage:220/380/415/450V,50Hz
